Fiberglass Mesh
White Resistance To High Temperature 60g- 4x4mesh Fiberglass Wire
Mesh Plain
Product Description
| Mesh size | 5x5 mesh, 5x4 mesh, 4x4 mesh, 3x3 mesh, 2.5x2.5 mesh, 1x1 mesh |
| Weight/square meter | 60g-300g |
| Each roll length | 10m, 20m, 30m, 50m-300m |
| Width | 0.5m-2m |
| Example of applications | 1).75g / m2 mesh fabric used in the reinforcement of thin slurry,
to eliminate small cracks and scattered throughout the surface
pressure.
2).110g / m2 mesh cloth is widely used in indoor and outdoor walls,
prevent the various materials (such as brick, light wood,
prefabricated structure) of treatment or caused by a variety of
expansion coefficient of wall crack and break .
3). 145g/m2 mesh fabric used in the wall and be mixed in various
materials (such as brick, light wood, prefabricated structures), to
prevent cracking the scatter and whole surface pressure, especially in the external wall
insulation system (EIFS ).
4). 160g / m2 mesh fabric used in insulator layer of reinforcement
in the mortar, through shrinkage and temperature changes by
providinga space to movement maintain between the layers,prevent crack and rupture due or
temperature change. |
| Mesh size | 16x16 mesh, 15x14 mesh, 12x12 mesh, 10x10 mesh, 9x9mesh, 8x8 mesh, 6x6 mesh |
| Weight/square meter | 40g-120g |
| Each roll length | 10m, 20m, 30m, 50m-300m |
| Width | 0.05m-2m |
| Packing | carton |
Hongye is home to a range of wire mesh products dedicated to
providing online sales and service, where you can find almost all
the related products. Some of the products are manufactured by our
factory in Anping (since 1995) and some by our partner factories.
All the products have been tested strictly before sales.
Hongye is proud of the people that work for us,the experienced
workers, strict inspectors and energetic sales, whose work
guarantees the best price, quality products and reliable service
for customers.
Hongye is always ready to be your one-stop supermarket for wire
mesh.
1. Material properties
Lightweight and high strength: Its weight is only 1/4 to 1/5 of
that of metal mesh, and its tensile strength can reach 1000 to
3000N/5cm, making it convenient for transportation and
construction.
Corrosion resistance: Resistant to acids and alkalis, anti-rust,
suitable for corrosive environments such as chemical and mining
industries.
High-temperature resistance: Long-term temperature resistance range
-50℃ to 500℃, which can meet the requirements of high-temperature
pipeline insulation, fire isolation, etc.
Uv resistance: With special coating treatment, the outdoor service
life is over 10 years.
Flexible and insulating: It can be bent to fit complex curved
surfaces and has electrical insulation properties, ensuring
construction safety.
2. Core application fields
Construction engineering
Wall crack resistance: Embedding a plastering layer to prevent wall
cracking and hollowing.
Concrete reinforcement: It is used for road and bridge
reinforcement to enhance impact resistance.
Waterproof base material: As the bottom support for the roof
waterproofing membrane.
Industrial field:
High-temperature equipment protection: Insulation layer framework
for boilers and pipelines.
Filtration and screening: Acid and alkali resistant filter screens
for mining and chemical plants.
Agricultural environmental protection
Greenhouse structure: Support shading nets and insect-proof nets to
extend the lifespan of the greenhouse.
Geotechnical reinforcement: Anti-seepage reinforcement layers for
landfill sites and river embankment slopes.
3. Advantages over traditional materials
Economy: Maintenance-free, long service life, and the overall cost
is lower than that of metal mesh.
Environmental friendliness: The production process has low energy
consumption, is recyclable, and conforms to the concept of
sustainable development.
Adaptability: Supports customized mesh size (1-10mm), specific
weight (80-400g/m²), and coatings (acrylic, polyurethane, etc.).
4. Future Development Trends
With the growing demand for green buildings and industrial
upgrading, glass fiber mesh fabric is innovating in the direction
of high-performance coatings (such as self-cleaning and
flame-retardant efficiency improvement), intelligent composites
(embedding sensors to monitor structural health), etc., further
expanding its application in emerging scenarios such as new energy
and 5G base stations
